1N3600 Compensated Deuices Incorporated
Same model may have multiple batches, images only for reference.

1N3600

Part No 1N3600
Manufacturer NTE
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 50V 200MA DO35 / Diode 50 V 200mA Through Hole DO-35
Datasheet
1N3600 Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr NTE
Package Bag
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 50 V
Current - Average Rectified (Io) 200mA
Voltage - Forward (Vf) (Max) @ If 1 V @ 200 mA
Speed Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr) 4 ns
Current - Reverse Leakage @ Vr 100 nA @ 50 V
Mounting Type Through Hole
Package / Case DO-204AH, DO-35, Axial
Supplier Device Package DO-35
Operating Temperature - Junction -65°C ~ 175°C
Standard Package 1 pcs
ECCN EAR99
HTSUS 8541.10.0070
Win Source Part Number 538992-1N3600
Ultra Librarian 3D Model Ultra Librarian 1N3600 CAD Model

Description

The NTE 1N3600 is a single rectifier diode with a maximum reverse voltage of 50V and an average rectified current of 200mA.

  • Package: Bag
  • Product Status: Active
  • Maximum Forward Voltage: 1V @ 200mA
  • Suitable for: Small signal applications
  • Reverse Recovery Time: 4ns
  • Reverse Leakage Current: 100nA @ 50V
  • Mounting Type: Through-hole
  • Package: DO-204AH axial
  • Operating Temperature Range: -65°C to 175°C
  • ECCN: EAR99
  • HTSUS Code: 8541.10.0070
