Product Overview: 74HC02D,653 from NXP Semiconductors

The 74HC02D,653 is a high-speed Si-gate CMOS device that is part of the 74HC series from NXP Semiconductors. This integrated circuit is designed to provide the functionality of quadruple 2-input NOR gates in a single chip. It is a versatile component commonly used in a variety of digital applications, from basic logic circuits to complex computing systems.

The 74HC02D,653 operates with a power supply voltage range of 2.0 to 6.0V, which makes it compatible with TTL (Transistor-Transistor Logic) levels. This allows for easy interfacing with other logic families and makes the chip suitable for use in mixed-voltage systems. The low power consumption and balanced propagation delays make it a preferred choice for power-sensitive and timing-critical applications.

Key Features:

• Logic Type: Quadruple 2-Input NOR Gate
• Package: The device comes in a SO14 (Small Outline) package, which is compact and suitable for surface-mount technology (SMT).
• Operating Voltage: 2.0V to 6.0V, making it suitable for interfacing with both 3.3V and 5V logic levels.
• High Noise Immunity: Ensures stable operation in electrically noisy environments.
• Low Power Dissipation: The CMOS technology used in the 74HC02D,653 results in low power consumption.
• High-Speed Performance: Fast propagation delays and transition times enable use in high-speed systems.

Applications:

The 74HC02D,653 is ideal for a wide range of applications, including:

• Logic function implementation
• Control systems
• Signal processing
• Computing devices
• Power management circuits
• Communication systems

With its robust design and high functionality, the 74HC02D,653 from NXP Semiconductors is a reliable choice for designers and engineers looking to implement NOR logic in their digital systems. Its compatibility with a broad range of supply voltages and other logic families, along with its small footprint, makes it an essential component for modern electronic designs.
