Product Overview: PSMN1R0-30YLC from NXP

The PSMN1R0-30YLC is a high-performance, N-channel enhancement mode Field-Effect Transistor (FET) designed and manufactured by NXP Semiconductors. This power MOSFET is tailored for efficient power management and conversion in a wide array of electronic applications, including but not limited to, DC-DC converters, motor drives, and power supplies.

Key Features

• Low On-Resistance: The PSMN1R0-30YLC boasts an exceptionally low on-resistance (R<sub>DS(on)) of just 1.0 mΩ at V<sub>GS = 10V, which results in reduced conduction losses and enhances overall efficiency.
• High Continuous Current: It is capable of supporting a continuous drain current (I<sub>D) of up to 380 A, making it suitable for high-power applications.
• 30V Drain-Source Voltage: With a maximum drain-source voltage (V<sub>DS) of 30V, this MOSFET can be employed in systems with moderate voltage requirements.
• Low Gate Charge: The low gate charge (Q<sub>g) facilitates faster switching speeds, which is critical in reducing switching losses and improving performance in high-frequency circuits.
• Robust Thermal Performance: The PSMN1R0-30YLC comes in a LFPAK56 (Power-SO8) package, which provides excellent thermal performance and reliability.

Applications

The versatility of the PSMN1R0-30YLC allows it to be integrated into a variety of applications such as:

• Power supply units for servers and telecom systems
• DC-DC converters for CPU and GPU power delivery
• Motor control systems in automotive and industrial settings
• Synchronous rectification in switched mode power supplies
• Power management solutions for battery-powered devices

Quality and Reliability

NXP Semiconductors is known for its commitment to quality and reliability, and the PSMN1R0-30YLC is no exception. It is designed to meet the stringent requirements of the industrial and automotive markets, ensuring long-term reliability and performance under various operating conditions.

With its combination of low on-resistance, high current capability, and efficient switching performance, the PSMN1R0-30YLC from NXP is an ideal choice for designers looking to optimize their power management systems.
