The ON Semiconductor NTBG022N120M3S is a state-of-the-art N-Channel Metal Oxide Semiconductor Field-Effect Transistor (MOSFET) designed for high-efficiency power management applications. This robust component is part of ON Semiconductor's extensive portfolio of energy-efficient devices, providing designers with a reliable and powerful solution for their circuit needs.

Key Features

• High Voltage Capability: With a drain-to-source voltage (V<sub>DS) of 1200V, the NTBG022N120M3S is suitable for high-voltage applications, ensuring reliable operation in demanding environments.
• Low On-Resistance: Featuring a low R<sub>DS(on) of 22 mΩ, this MOSFET minimizes power loss during operation, leading to improved overall efficiency and thermal performance.
• Fast Switching Speed: The device is optimized for fast switching, reducing switching losses and enabling higher frequency operation in power conversion systems.
• Enhanced Thermal Performance: The NTBG022N120M3S comes in a compact DFN8 package with a thermal resistance that ensures efficient heat dissipation, contributing to the longevity and reliability of the device.
• Robust Body Diode: The integrated body diode is characterized by a low reverse recovery charge (Q<sub>rr), which is advantageous in hard-switching applications and further reduces power losses.

Applications

The NTBG022N120M3S is versatile and can be used in a variety of applications, including:

• Power supply units (PSUs)
• DC-DC converters
• Motor drives
• Power inverters
• Electric vehicle (EV) charging stations
• Renewable energy systems, such as solar inverters and wind turbines

Quality and Reliability

ON Semiconductor is committed to providing high-quality products that meet stringent industry standards. The NTBG022N120M3S is no exception, offering designers a reliable MOSFET that delivers both performance and energy efficiency. With its advanced features and robust design, this component is ideal for designing next-generation power management systems.
