ISL8210MEVAL1Z Real Image
Same model may have multiple batches, images only for reference.

ISL8210MEVAL1Z

Part No ISL8210MEVAL1Z
Manufacturer Renesas Electronics America
Catalog Evaluation Boards - DC/DC & AC/DC (Off - Line)SMPS
Description EVAL BRD FOR ISL8210M  /  ISL8210M series DC/DC, Step Down 1, Non-Isolated Outputs Evaluation Board
Datasheet
ISL8210MEVAL1Z Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Development Boards, Kits, Programmers>Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
Mfr Renesas Electronics America Inc
Package Bulk
Product Status Obsolete
Main Purpose DC/DC, Step Down
Outputs and Type 1, Non-Isolated
Voltage - Output 1V
Current - Output 10A
Voltage - Input 4.5V ~ 15V
Regulator Topology Buck
Frequency - Switching 400kHz
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part ISL8210M
Base Product Number ISL8210
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9580
Other Names -ISL8210MEVAL1Z
Standard Package 1
Win Source Part Number 968452-ISL8210MEVAL1Z
Ultra Librarian 3D Model Ultra Librarian ISL8210MEVAL1Z CAD Model

Description

The Renesas Electronics America Inc ISL8210MEVAL1Z is a development board that is fully populated and utilizes the ISL8210M IC/part.

  • Application: DC/DC, Step-Down
  • Voltage Output: 1V
  • Current Output: 10A
  • Input Voltage: 4.5V to 15V
  • Regulator Topology: Buck
  • Packaging: Bulk
  • Standard Package: 1
  • Frequency Switching: 400kHz
  • Supplied With: Board(s)
  • MSL Level: 1 (Unlimited)
  • REACH Status: Unaffected
  • Manufacturer: Renesas Electronics America Inc
