The ST2L05R3300PT is a high-performance, low-dropout voltage regulator designed by STMicroelectronics, one of the leading manufacturers in the semiconductor industry. This regulator is specifically engineered to deliver a stable and precise voltage supply, making it an ideal choice for sensitive electronic applications where voltage accuracy is critical.

Key Features

• Output Voltage: The ST2L05R3300PT provides a fixed output voltage of 3.3V, which is a common requirement for many digital and analog circuits.
• Low Dropout: With its low dropout performance, it operates efficiently even when the input voltage is very close to the output voltage, reducing power loss and improving overall system efficiency.
• High Current Capability: This regulator can deliver up to 500mA of continuous output current, suitable for a wide range of applications.
• Thermal Protection: It includes thermal shutdown protection that safeguards the device and the system from damage due to overheating.
• Short-Circuit Protection: The built-in short-circuit protection feature ensures that the regulator and the connected load are protected in the event of a fault condition.

Applications

The versatility of the ST2L05R3300PT allows it to be used in various applications, including but not limited to:

• Consumer Electronics
• Automotive Systems
• Telecommunication Devices
• Computer Peripherals
• Power Management Solutions

Quality and Reliability

STMicroelectronics is known for its commitment to quality, and the ST2L05R3300PT is no exception. It is built to meet the highest standards of reliability and performance, ensuring that it can withstand the rigors of everyday use in a variety of environments.

Package Information

The ST2L05R3300PT is available in a TO-220 package, which is widely used in the industry and is known for its robustness and ease of handling. This package is suitable for through-hole mounting, which adds to the mechanical stability of the mounted device.

With its combination of features, the ST2L05R3300PT is a versatile and reliable choice for designers looking to incorporate a dependable voltage regulator into their electronic systems.
