STMicroelectronics STD140N6F7 Power MOSFET

The STD140N6F7 is a high-performance N-channel Power MOSFET produced by STMicroelectronics, a leader in semiconductor solutions. This device is designed to meet a wide range of energy-efficient applications, particularly in power supply and power conversion systems. It is part of STMicroelectronics' STripFET™ VII DeepGATE™ technology, which ensures optimized on-state resistance and superior switching performance.

Key Features

• Low On-Resistance: The STD140N6F7 boasts an exceptionally low on-resistance (R_DS(on)), which reduces conduction losses and improves overall efficiency.
• High Current Capability: With a continuous drain current (I_D) of 80A, this MOSFET can handle high current loads, making it suitable for demanding applications.
• High Switching Speed: The device's fast switching speed is ideal for high-frequency power switching applications.
• 100% Avalanche Tested: Each unit is rigorously tested for avalanche ruggedness, ensuring reliability under extreme conditions.
• Low Gate Charge: The low gate charge (Q_g) of the STD140N6F7 facilitates efficient switching performance and reduces power dissipation.

Applications

The versatility of the STD140N6F7 makes it suitable for a variety of applications, including:

• High-efficiency DC/DC converters
• Synchronous rectification for switch mode power supplies (SMPS)
• Motor control drivers
• Load switches
• Battery management systems

Technical Specifications

With its robust performance and high reliability, the STD140N6F7 from STMicroelectronics is an excellent choice for designers seeking a power MOSFET that delivers both efficiency and durability.
