LM1117MPX-5.0/NOPB Texas Instruments LM1117MPX-5.0/NOPB Real Image LM1117MPX-5.0/NOPB real image LM1117MPX-5.0/NOPB real image971 LM1117MPX-5.0/NOPB Real Image
Same model may have multiple batches, images only for reference.
LM1117MPX-5.0/NOPB Texas Instruments LM1117MPX-5.0/NOPB Real Image LM1117MPX-5.0/NOPB real image LM1117MPX-5.0/NOPB real image971 LM1117MPX-5.0/NOPB Real Image
LM1117MPX-5.0/NOPB Texas Instruments LM1117MPX-5.0/NOPB Real Image LM1117MPX-5.0/NOPB real image LM1117MPX-5.0/NOPB real image971 LM1117MPX-5.0/NOPB Real Image
Same model may have multiple batches, images only for reference.

LM1117MPX-5.0/NOPB

Part No LM1117MPX-5.0/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description LDO Regulator Pos 5V 0.8A 4-Pin(3+Tab) SOT-223 T/R / IC REG LDO 5V 0.8A SOT223
Datasheet
LM1117MPX-5.0/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 15V
Nominal Output Voltage (Min/Fixed) 5V
Dropout Voltage-Max 1.2V @ 800mA
Output Current 800mA
Operating Supply Current 5mA to 10mA
PSRR 75dB (120Hz)
Control Protection Features Over Current, Over Temperature
Temperature Range - Operating 0°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 5V
Voltage - Dropout (Typical) 1.2V @ 800mA
Mounting SMD (SMT)
Case / Package SOT-223-4
Win Source Part Number 018652-LM1117MPX-5.0/NOPB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management
Family Name LM1117
Introduction Date June 01, 1998
ECCN EAR99
Country of Origin China, Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LM1117MPX-5.0/NOPB CAD Model

Description

The LM1117MPX-5.0/NOPB is a superior quality voltage regulator manufactured by Texas Instruments, a global leader in semiconductor technology and integrated circuits.

  • Output Voltage: 5.0V
  • Output Tolerance: 1%
  • Output Current: 800mA
  • Input Voltage Range: 1.0V to 10V
  • Dropout Voltage: Typically 1.2V @ maximum output
  • Safety Features: Built-in current limiting and thermal shutdown
  • Package: Compact SOT-223
  • Compliance: RoHS compliant and free from lead (Pb)
