The Vishay IRF740ASTRLPBF is an N-channel MOSFET designed for use in a variety of applications.

• Maximum Power Dissipation: 125W @ a case temperature of 25°C
• Drain-Source Breakdown Voltage: 400V
• Continuous Drain Current: 10A @ a case temperature of 25°C
• Gate-Source Threshold Voltage: 4V @ 250μA
• Maximum Gate Charge: 36nC @ 10V
• Maximum Input Capacitance: 1030pF @ 25V
• Maximum Rds On @ Id,Vgs: 550 mOhm @ 6A, 10V
• Package: D2PAK
• Operating Temperature Range: -55°C to 150°C
• Suitable for: use in a wide range of applications, including power supplies, motor control, and lighting
