SI4804CDY-T1-E3 Real Image SI4804CDY-T1-E3 Real Image1 SI4804CDY-T1-E3 Real Image2 SI4804CDY-T1-E3 Real Image3
Same model may have multiple batches, images only for reference.
SI4804CDY-T1-E3 Real Image SI4804CDY-T1-E3 Real Image1 SI4804CDY-T1-E3 Real Image2 SI4804CDY-T1-E3 Real Image3
SI4804CDY-T1-E3 Real Image SI4804CDY-T1-E3 Real Image1 SI4804CDY-T1-E3 Real Image2 SI4804CDY-T1-E3 Real Image3
Same model may have multiple batches, images only for reference.

SI4804CDY-T1-E3

Part No SI4804CDY-T1-E3
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET 2N-CH 30V 8A 8SO
Datasheet
SI4804CDY-T1-E3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
FET Type 2 N-Channel (Dual)
FET Feature Standard
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 8A
Maximum Rds On at Id,Vgs 22 mOhm @ 7.5A, 10V
Gate-Source Threshold Voltage 2.4V @ 250μA
Max Gate Charge 23nC @ 10V
Max Input Capacitance 865pF @ 15V
Maximum Power Dissipation 3.1W
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 1096007-SI4804CDY-T1-E3
Popularity Medium
Supply and Demand Status Sufficient
Application Field Used in Industrial
Ultra Librarian 3D Model Ultra Librarian SI4804CDY-T1-E3 CAD Model

Description

The Vishay SI4804CDY-T1-E3 is a 2 N-Channel (Dual) FET with a standard feature.

  • FET Type: 2 N-Channel (Dual)
  • Feature: Standard
  • Mounting: Surface-mount
  • Package: 8-SO
  • Power Dissipation: 3.1W
  • Drain-Source Breakdown Voltage: 30V
  • Continuous Drain Current: 8A @ 25°C
  • Gate-Source Threshold Voltage: 2.4V @ 250μA
  • Maximum Gate Charge: 23nC @ 10V
  • Maximum Input Capacitance: 865pF @ 15V
  • Maximum Rds On @ Id,Vgs: 22 mOhm @ 7.5A, 10V
  • Operating Temperature Range: -55°C to 150°C (TJ)
  • Application: Industrial
