SISH625DN-T1-GE3 Real Image SISH625DN-T1-GE3 Real Image1 SISH625DN-T1-GE3 Real Image2
Same model may have multiple batches, images only for reference.
SISH625DN-T1-GE3 Real Image SISH625DN-T1-GE3 Real Image1 SISH625DN-T1-GE3 Real Image2
SISH625DN-T1-GE3 Real Image SISH625DN-T1-GE3 Real Image1 SISH625DN-T1-GE3 Real Image2
Same model may have multiple batches, images only for reference.

SISH625DN-T1-GE3

Part No SISH625DN-T1-GE3
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 30V 17.3A/35A PPAK
Datasheet
SISH625DN-T1-GE3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr Vishay
Series TrenchFET®
Package Tape & Reel
Product Status Active
FET Type P-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 30 V
Current - Continuous Drain (Id) @ 25°C 17.3A (Ta), 35A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Rds On (Max) @ Id, Vgs 7mOhm @ 15A, 10V
Vgs(th) (Max) @ Id 2.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs 126 nC @ 10 V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 4427 pF @ 15 V
Power Dissipation (Max) 3.7W (Ta), 52W (Tc)
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Supplier Device Package PowerPAK® 1212-8SH
Package / Case PowerPAK® 1212-8SH
Base Product Number SISH625
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.29.0095
Win Source Part Number 849557-SISH625DN-T1-GE3
Ultra Librarian 3D Model Ultra Librarian SISH625DN-T1-GE3 CAD Model

Description

The Vishay 849557-SISH625DN-T1-GE3 is a P-Channel MOSFET transistor designed for discrete semiconductor applications by Vishay.

  • Series: TrenchFET series
  • Application: Efficient power management
  • Packaging: Tape and reel
  • Drain to Source Voltage (Vdss): 30V
  • Continuous Drain Current (Id): 17.3A @ 25°C
  • Rds On (Max): 7mOhm @ 15A and 10V gate-source voltage
  • Gate Threshold Voltage (Vgs(th)): 2.5V @ 250µA
  • Maximum Power Dissipation: 3.7W @ 25°C and 52W @ the case
  • Mounting: Surface mount
  • Package: PowerPAK 1212-8SH
  • Gate Charge (Qg): 126nC @ 10V
  • Temperature Range: -55°C to 150°C
  • Product Status: Active
