FDD8447L Real Image FDD8447L label picture FDD8447L real image4057 FDD8447L Real Image1 FDD8447L Real Image2 FDD8447L Real Image3
Same model may have multiple batches, images only for reference.
FDD8447L Real Image FDD8447L label picture FDD8447L real image4057 FDD8447L Real Image1 FDD8447L Real Image2 FDD8447L Real Image3
FDD8447L Real Image FDD8447L label picture FDD8447L real image4057 FDD8447L Real Image1 FDD8447L Real Image2 FDD8447L Real Image3
Same model may have multiple batches, images only for reference.

FDD8447L

Part No FDD8447L
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 40V 15.2A DPAK
Datasheet
FDD8447L Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 40V
Continuous Drain Current at 25°C 15.2A (Ta), 50A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 3V @ 250μA
Max Gate Charge 52nC @ 10V
Max Input Capacitance 1970pF @ 20V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 3.1W (Ta), 44W (Tc)
Maximum Rds On at Id,Vgs 8.5 mOhm @ 14A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package D-PAK (TO-252AA)
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 092767-FDD8447L
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management, Industrial
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian FDD8447L CAD Model

Description

The FDD8447L is a highly efficient N-channel MOSFET designed for high-performance applications. This device is suitable for low-voltage switching applications and features a low on-state resistance, making it an excellent choice for power management tasks.

Features and Benefits

  • Low on-state resistance for higher efficiency and reduced power loss
  • Fast switching capability to meet demanding applications
  • Compact package design for space-saving in crowded PCBs

Applications

  • DC-DC converters
  • Load switch applications
  • Motor control circuits
  • Power management in mobile devices

The FDD8447L ensures optimal performance in any electronic project where efficient power switching is crucial.
