FQA24N50 Real Image FQA24N50 real image FQA24N50 real image4242 FQA24N50 Real Image
Same model may have multiple batches, images only for reference.
FQA24N50 Real Image FQA24N50 real image FQA24N50 real image4242 FQA24N50 Real Image
FQA24N50 Real Image FQA24N50 real image FQA24N50 real image4242 FQA24N50 Real Image
Same model may have multiple batches, images only for reference.

FQA24N50

Part No FQA24N50
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 500V 24A TO-3PN
Datasheet
FQA24N50 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Obsolete(EOL)
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 500V
Continuous Drain Current at 25°C 24A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 5V @ 250μA
Max Gate Charge 120nC @ 10V
Max Input Capacitance 4500pF @ 25V
Maximum Gate-Source Voltage ±30V
Power Dissipation (Max) 290W (Tc)
Maximum Rds On at Id,Vgs 200 mOhm @ 12A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-3PN
Dimension TO-3P-3, SC-65-3
Win Source Part Number 111473-FQA24N50
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian FQA24N50 CAD Model

Description

The Fairchild/ON Semiconductor FQA24N50 is an N-Channel MOSFET.

  • Power Dissipation: 290W (Tc)
  • Drain-Source Breakdown Voltage: 500V
  • Continuous Drain Current: 24A (Tc) @ 25°C
  • Package: TO-3PN
  • Gate-Source Threshold Voltage: 5V @ 250μA
  • Category: Discrete Semiconductor Products
  • Status: Obsolete(EOL)
  • Supply and Demand: Limited
