NDT2955 Fairchild/ON Semiconductor NDT2955 Real Image NDT2955 real image NDT2955 real image4026 NDT2955 real image4027 NDT2955 Real Image1 NDT2955 Real Image2 NDT2955 Real Image3 NDT2955 Real Image4 NDT2955 Real Image5 NDT2955 Real Image6 NDT2955 Real Image7 NDT2955 Real Image8 NDT2955 Real Image9 NDT2955 Real Image10 NDT2955 Real Image11 NDT2955 Real Image12
Same model may have multiple batches, images only for reference.
NDT2955 Fairchild/ON Semiconductor NDT2955 Real Image NDT2955 real image NDT2955 real image4026 NDT2955 real image4027 NDT2955 Real Image1 NDT2955 Real Image2 NDT2955 Real Image3 NDT2955 Real Image4 NDT2955 Real Image5 NDT2955 Real Image6 NDT2955 Real Image7 NDT2955 Real Image8 NDT2955 Real Image9 NDT2955 Real Image10 NDT2955 Real Image11 NDT2955 Real Image12
NDT2955 Fairchild/ON Semiconductor NDT2955 Real Image NDT2955 real image NDT2955 real image4026 NDT2955 real image4027 NDT2955 Real Image1 NDT2955 Real Image2 NDT2955 Real Image3 NDT2955 Real Image4 NDT2955 Real Image5 NDT2955 Real Image6 NDT2955 Real Image7 NDT2955 Real Image8 NDT2955 Real Image9 NDT2955 Real Image10 NDT2955 Real Image11 NDT2955 Real Image12
Same model may have multiple batches, images only for reference.

NDT2955

Part No NDT2955
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 60V 2.5A SOT-223-4
Datasheet
NDT2955 Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 2.5A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 15nC @ 10V
Max Input Capacitance 601pF @ 30V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 3W (Ta)
Maximum Rds On at Id,Vgs 300 mOhm @ 2.5A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-223-4
Dimension TO-261-4, TO-261AA
Win Source Part Number 025178-NDT2955
Family Name NDT2955
Introduction Date March 03, 1998
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management, Consumer Electronics, Portable Devices, Industrial
Quantity per package 4k pcs
Ultra Librarian 3D Model Ultra Librarian NDT2955 CAD Model

Description

The Fairchild/ON Semiconductor NDT2955 is a P-channel MOSFET transistor that is used in power management, consumer electronics, portable devices, and industrial applications.

  • Case/Package: TO-223-4
  • Dimension: TO-261-4, TO-261AA
  • Continuous Drain Current @ 25°C: 2.5A
  • Drain-Source Breakdown Voltage: 60V
  • Popularity: High
  • Supply and Demand Status: Balanced
  • Max Input Capacitance: 601pF @ 30V
  • Max Gate Charge: 15nC @ 10V
