BSP315PH6327XTSA1 Infineon Technologies BSP315PH6327XTSA1 Real Image
Same model may have multiple batches, images only for reference.
BSP315PH6327XTSA1 Infineon Technologies BSP315PH6327XTSA1 Real Image
BSP315PH6327XTSA1 Infineon Technologies BSP315PH6327XTSA1 Real Image
Same model may have multiple batches, images only for reference.

BSP315PH6327XTSA1

Part No BSP315PH6327XTSA1
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 60V 1.17A SOT-223
Datasheet
BSP315PH6327XTSA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 1.17A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2V @ 160μA
Max Gate Charge 7.8nC @ 10V
Max Input Capacitance 160pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 1.8W (Ta)
Maximum Rds On at Id,Vgs 800 mOhm @ 1.17A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package PG-SOT223-4
Dimension TO-261-4, TO-261AA
Win Source Part Number 112545-BSP315PH6327XTSA1
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BSP315PH6327XTSA1 CAD Model

Description

Description

The BSP315PH6327XTSA1 is an advanced electronic component designed to deliver high performance and efficiency in demanding applications. It is robust and versatile, providing solutions to complex electronic challenges.

Applications

  • High-frequency Circuit Design
  • Advanced Computing Systems
  • Energy-Efficient Appliances
  • Advanced Automotive Systems

Features and Benefits

  • Performance Optimization: Enhances system speed and functionality.
  • Robust Construction: Built to withstand extreme operating conditions.
  • Low Power Profile: Aids in reducing overall energy consumption.
  • Flexible Integration: Easily adaptable to a broad spectrum of electronic setups.

The BSP315PH6327XTSA1 is perfect for engineers and developers aiming for top-tier performance and reliability in their electronic systems.
