Same model may have multiple batches, images only for reference.

IRF7410TRPBF

Name: IRF7410TRPBF
Brand: Infineon Technologies
SKU: 159926
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRF7410TRPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 12V 16A 8-SOIC
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	12V
Continuous Drain Current at 25°C	16A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	1.8V, 4.5V
Gate-Source Threshold Voltage	900mV @ 250μA
Max Gate Charge	91nC @ 4.5V
Max Input Capacitance	8676pF @ 10V
Maximum Gate-Source Voltage	±8V
Power Dissipation (Max)	2.5W (Ta)
Maximum Rds On at Id,Vgs	7 mOhm @ 16A, 4.5V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-SO
Dimension	8-SOIC (0.154", 3.90mm Width)
Win Source Part Number	101432-IRF7410TRPBF
Family Name	IRF7410
Introduction Date	August 25, 2006
ECCN	EAR99
Country of Origin	China, Philippines
Halogen Free	Compliant
Estimated EOL Date	2024
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian IRF7410TRPBF CAD Model

Alternative Products

Description

The IRF7410TRPBF MOSFET is a P-Channel polarity electronic component manufactured by Infineon Technologies.

Product: discrete semiconductor product
Power Dissipation: 2.5W (Ta)
Drain-Source Breakdown Voltage: 12V
Continuous Drain Current @ 25°C: 16A (Ta)
Gate-Source Threshold Voltage: 900mV @ 250μA
Maximum Rds On @ Id,Vgs: 7 mOhm @ 16A, 4.5V
Suitable for: applications such as power management and motor drive & control
Package: 8-SO
Temperature Range: -55°C to 150°C (TJ)
