IRFB4310ZGPBF Real Image IRFB4310ZGPBF real image325
Same model may have multiple batches, images only for reference.
IRFB4310ZGPBF Real Image IRFB4310ZGPBF real image325
IRFB4310ZGPBF Real Image IRFB4310ZGPBF real image325
Same model may have multiple batches, images only for reference.

IRFB4310ZGPBF

Part No IRFB4310ZGPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 100V 120A TO-220AB
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Obsolete(EOL)
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 120A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 150μA
Max Gate Charge 170nC @ 10V
Max Input Capacitance 6860pF @ 50V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 250W (Tc)
Maximum Rds On at Id,Vgs 6 mOhm @ 75A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-220AB
Dimension TO-220-3
Win Source Part Number 040709-IRFB4310ZGPBF
Popularity Medium
Supply and Demand Status Balance
Quantity per package 50
Ultra Librarian 3D Model Ultra Librarian IRFB4310ZGPBF CAD Model

Description

The IRFB4310ZGPBF is a N-Channel MOSFET from Infineon Technologies.

  • Applications: Power supplies, motor drives, and DC-DC converters
  • Maximum Power Dissipation: 250W
  • Continuous Drain Current: 120A @ 25°C
  • Drain-Source Breakdown Voltage: 100V
  • Maximum Rds On: 6 mOhm @ 75A, 10V
  • Gate-Source Threshold Voltage: 4V @ 150μA
  • Maximum Gate Charge: 170nC @ 10V
  • Package: TO-220AB
  • Packaging: Tube/Rail
  • Popularity: Medium
  • Supply and Demand Status: Balanced
  • Quantity per Package: 50
