The MAX2135AETN/V+ from Maxim Integrated is a state-of-the-art digital satellite tuner integrated circuit (IC) designed to provide exceptional performance for satellite television (TV) and satellite digital radio applications. This advanced tuner IC is engineered to offer high integration, which reduces the external component count and simplifies the design process for manufacturers, ultimately leading to a more compact and cost-effective end product.

Key Features

• High Integration: The MAX2135AETN/V+ integrates a complete satellite receiver function from RF to baseband, including a low-noise amplifier (LNA), a down-conversion mixer, an on-chip phase-locked loop (PLL), and a variable gain amplifier (VGA).
• Wide Frequency Range: It supports a broad range of input frequencies, making it suitable for a variety of satellite communication standards.
• Low Power Consumption: Designed with power efficiency in mind, it operates with low power consumption, which is crucial for portable and energy-sensitive applications.
• High Performance: The device delivers excellent sensitivity and linearity, ensuring high-quality signal reception under various conditions.
• Small Form Factor: Housed in a compact 40-pin thin QFN package, the MAX2135AETN/V+ saves valuable board space.

Applications

The versatility of the MAX2135AETN/V+ makes it ideal for a range of applications, including:

• Satellite TV receivers
• Satellite radio receivers
• Set-top boxes
• Personal video recorders (PVRs)
• Automotive satellite radio and TV systems

Technical Specifications

With a comprehensive set of features, the MAX2135AETN/V+ is designed to meet the rigorous demands of modern satellite communication systems:

• Supply Voltage: 3.3V ±5%
• Operating Temperature Range: -40°C to +85°C
• Package Type: 40-TQFN-EP

The MAX2135AETN/V+ is a testament to Maxim Integrated's commitment to providing innovative solutions that push the boundaries of satellite communication technology. Its integration, performance, and compact design make it a top choice for designers looking to develop the next generation of satellite reception equipment.
