Microchip Technology MCP40D17T-503E/LT Digital Potentiometer

The MCP40D17T-503E/LT is a high-performance digital potentiometer integrated circuit crafted by Microchip Technology, a leading provider of smart, connected, and secure embedded control solutions. This compact and versatile component is designed to offer precise resistance tuning in a wide range of electronic applications, from automated adjustments in consumer electronics to calibration settings in industrial systems.

Key Features

• Resistance Value: The MCP40D17T-503E/LT offers a maximum resistance of 50kΩ, providing ample range for various applications that require fine-tuning of resistance.
• Resolution: With 7-bits (128 wiper steps), this digital potentiometer allows for incremental adjustments, enabling precise setting of resistance values.
• Interface: The device is equipped with an I2C™ compatible interface, ensuring easy communication with microcontrollers and other digital systems.
• Single Supply Operation: It operates with a single supply voltage ranging from 2.7V to 5.5V, making it suitable for both 3.3V and 5V systems.
• Temperature Range: The extended temperature range of -40°C to +125°C ensures reliable performance in harsh environmental conditions.
• Package: The MCP40D17T-503E/LT comes in a compact, 6-lead SC-70 package, which is ideal for space-constrained applications.
• Non-volatile Memory: It features non-volatile memory (EEPROM) to store the wiper position, ensuring the last set resistance value is maintained even after power-off.

Applications

The versatility of the MCP40D17T-503E/LT makes it suitable for a broad spectrum of applications. It's commonly used in:

• Automated product calibration
• Adjustable power supplies and voltage dividers
• Audio/visual equipment for volume and tone control
• Gain control and offset adjustment in sensors and instrumentation
• Automotive electronics for system tuning

With its precise control, ease of integration, and robust performance, the MCP40D17T-503E/LT digital potentiometer from Microchip Technology stands out as an excellent choice for designers looking to add adjustable resistance capabilities to their electronic systems.
