PMV20ENR Real Image PMV20ENR real image10955
Same model may have multiple batches, images only for reference.
PMV20ENR Real Image PMV20ENR real image10955
PMV20ENR Real Image PMV20ENR real image10955
Same model may have multiple batches, images only for reference.

PMV20ENR

Part No PMV20ENR
Manufacturer Nexperia USA Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 30V SOT23
Datasheet
PMV20ENR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 6A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2V @ 250μA
Max Gate Charge 10.8nC @ 10V
Max Input Capacitance 435pF @ 15V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 510mW (Ta), 6.94W (Tc)
Maximum Rds On at Id,Vgs 21 mOhm @ 6A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package TO-236AB (SOT23)
Dimension TO-236-3, SC-59, SOT-23-3
Win Source Part Number 1089777-PMV20ENR
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PMV20ENR CAD Model

Description

The Nexperia USA Inc. PMV20ENR is a surface mountable N-channel MOSFET with a drain-source breakdown voltage of 30V and a continuous drain current of 6A (Ta).

  • Manufacturer: Nexperia USA Inc.
  • Mounting Type: Surface Mountable
  • Channel Type: N-channel MOSFET
  • Drain-Source Breakdown Voltage: 30V
  • Continuous Drain Current: 6A (Ta)
  • Gate-Source Threshold Voltage: 2V @ 250μA
  • Maximum Gate Charge: 10.8nC @ 10V
  • Maximum Input Capacitance: 435pF @ 15V
  • Maximum Gate-Source Voltage: ±20V
  • Maximum Rds On @ Id,Vgs: 21 mOhm @ 6A, 10V
  • Supply and Demand Status: Sufficient
  • Common Application: Discrete Semiconductor Products
