Product Overview: MMBT2222AM3T5G from ON Semiconductor

The MMBT2222AM3T5G is a high-performance NPN bipolar junction transistor (BJT) from ON Semiconductor, a leading provider of semiconductor-based solutions. This transistor is designed for general-purpose amplifier and switching applications, featuring a compact surface-mount package that makes it ideal for space-constrained applications.

Key Features

• Device Type: NPN BJT
• Package: SOT-23, a small outline transistor package that is widely used in consumer electronics due to its small size and excellent power handling capabilities.
• Collector-Emitter Voltage (Vceo): 40V, which provides a good balance between performance and robustness for a wide range of applications.
• Collector Current (Ic): 600mA, allowing the device to handle moderate levels of current for amplification or switching purposes.
• DC Current Gain (hFE): 100 to 300 at Ic = 10mA, ensuring a consistent and reliable gain across various operating conditions.
• Power Dissipation: 225mW, suitable for low to medium power applications without requiring significant heat sinking.
• Operating and Storage Junction Temperature Range: -55°C to +150°C, providing a wide range of thermal stability for use in harsh environments.
• RoHS Compliant: Yes, ensuring compliance with environmental regulations and a commitment to sustainability.

Applications

The MMBT2222AM3T5G is versatile and can be used in a variety of applications, including:

• Signal amplification in audio and video equipment
• Driver stages in hi-fi amplifiers and television circuits
• Switching loads in computers and peripherals
• Control circuits in power management systems
• Telecommunication circuits

Quality and Reliability

ON Semiconductor is known for its commitment to quality and reliability, and the MMBT2222AM3T5G is no exception. It undergoes rigorous testing to ensure it meets the high standards expected of ON Semiconductor products. Engineers and designers can confidently incorporate this transistor into their designs, knowing it will deliver stable performance over its lifespan.

Whether you're designing consumer electronics, industrial control systems, or automotive applications, the MMBT2222AM3T5G offers the performance and reliability you need in a compact, surface-mount package.
