STB30NF10T4 - N-Channel MOSFET by STMicroelectronics

The STB30NF10T4 is a high-performance N-Channel MOSFET designed and manufactured by STMicroelectronics, a leader in semiconductor solutions. This device is engineered to deliver exceptional power efficiency and reliability for a wide range of applications, including switch-mode power supplies, DC-DC converters, motor control, and general-purpose switching applications.

Key Features

• Low Threshold Drive: The STB30NF10T4 operates at a low gate threshold voltage, making it suitable for low-voltage applications and ensuring easy drive capability.
• High Current Capability: With a continuous drain current (ID) of 30A, this MOSFET can handle high current loads, making it ideal for demanding power applications.
• Low On-Resistance: A low on-state resistance (RDS(on)) of 0.040 ohm minimizes conduction losses and improves overall efficiency, which is critical for power management circuits.
• 100% Avalanche Tested: Each unit is rigorously tested for avalanche energy (EAS) to ensure robustness and reliability in harsh conditions.
• Exceptional Ruggedness: The device is designed to withstand high energy pulses in the avalanche and commutation modes, offering enhanced durability and performance stability.

Applications

The versatility of the STB30NF10T4 allows it to be used in a variety of applications, including:

• Power supply units
• DC-DC converters
• Motor control systems
• High-efficiency switching circuits
• Power management solutions

Product Specifications

The STB30NF10T4 boasts the following specifications:

• Voltage - Rated: 100V
• Current Rating: 30A
• RDS(on): 0.040 ohm
• Package / Case: D2PAK

STMicroelectronics' commitment to quality and performance is evident in the STB30NF10T4 N-Channel MOSFET. This component represents a reliable and efficient solution for designers looking to optimize their power management systems.
