The TPS2560DRCRG4 is a sophisticated, dual-channel power distribution switch designed by Texas Instruments to cater to the needs of applications requiring power management with a protective edge. This component is engineered to provide a compact and efficient solution for USB and other hot-swap applications.

Key Features

• Adjustable Current-Limit Thresholds: Users can set the current limits to meet the specific requirements of their application, ensuring devices are protected from excessive current draw.
• Dual-Channel Design: The TPS2560DRCRG4 features two independent channels, providing flexibility in managing power distribution for multiple devices.
• High Accuracy: The device boasts a precise current-limit threshold, ensuring reliable operation and protection for connected devices.
• Fast Overcurrent Response: With a quick response to overcurrent conditions, this switch helps to prevent damage to the host and downstream devices.
• Under-Voltage Lockout (UVLO): The UVLO feature ensures that the switch remains off when the input voltage is too low, protecting the circuitry.

Applications

The TPS2560DRCRG4 is ideal for a variety of applications, including:

• USB hubs and peripherals
• Hot-swap power supplies
• Portable consumer electronics
• Industrial and automotive applications

Technical Specifications

The device operates over a voltage range of 2.5V to 6.5V, which covers most low-voltage power rails. It comes in a compact 10-pin VSON package, making it suitable for space-constrained applications. The TPS2560DRCRG4 also features built-in thermal shutdown protection and is capable of handling continuous current up to 1.5A per channel.

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the TPS2560DRCRG4 is no exception. This product is built to meet the rigorous standards of the industry, ensuring high performance and reliability for critical applications.

Ordering Information

The TPS2560DRCRG4 is available for order, and its technical documentation, including datasheets and design resources, can be found on the Texas Instruments website.
