The TXS0102DQMR is a state-of-the-art bidirectional voltage-level translator from the renowned semiconductor manufacturer, Texas Instruments. This compact device is designed to bridge the gap between different voltage domains, particularly in multi-voltage digital system applications. It is a part of the TXS series, which is known for its high-speed, non-inverting, and low-power performance.

Key Features

• Two-Bit Bidirectional Translator: The TXS0102DQMR is capable of translating signals between two different voltage levels across its two channels, making it ideal for applications that require a seamless interface between different logic levels.
• Auto-Direction Sensing: This device does not require a direction control signal, as it automatically senses and adjusts the direction of data flow, simplifying the design and reducing control line requirements.
• Wide Voltage Range: It supports a V<sub>CCA range of 1.65 V to 3.6 V and a V<sub>CCB range of 2.3 V to 5.5 V, accommodating a broad spectrum of logic levels and enabling compatibility with various microcontrollers and digital interfaces.
• Low Standby Current: The low standby current consumption makes it particularly suitable for battery-operated applications, ensuring energy efficiency and longer battery life.
• ESD Protection: The device includes integrated Electrostatic Discharge (ESD) protection circuits, which shield it against the damaging effects of static electricity and enhance its robustness in harsh environments.

Applications

The TXS0102DQMR is versatile and can be used in numerous applications due to its ability to facilitate communication between devices operating at different voltage levels. Common applications include:

• Mobile Phones
• Portable Electronics
• Computers and Peripherals
• Data Communication Systems
• Consumer Electronics

Package and Quality

The TXS0102DQMR comes in a DQFN (Dual Quad Flat No-Leads) package, which is highly space-efficient and suitable for compact circuit board designs. Texas Instruments' commitment to quality ensures that this product meets the rigorous industry standards for performance and reliability.
