MMSTA42 Real Image
Same model may have multiple batches, images only for reference.

MMSTA42

Part No MMSTA42
Manufacturer Yangzhou yangjie electronic co., ltd
Catalog Transistors (BJT) - Single
Description SOT-323 NPN 0.2W 0.1A 300V Trans
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - Bipolar (BJT) - Single Bipolar Transistors
Mfr Yangzhou yangjie electronic co., ltd
Package Tape & Reel
Product Status Active
Transistor Type NPN
Current - Collector (Ic) (Max) 200 mA
Voltage - Collector Emitter Breakdown (Max) 300 V
Vce Saturation (Max) @ Ib, Ic 500mV @ 2mA, 20mA
Current - Collector Cutoff (Max) 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce 40 @ 30mA, 10V
Power - Max 200 mW
Frequency - Transition 50MHz
Temperature Range - Operating -55°C ~ 150°C
Mounting Type Surface Mount
Package / Case SC-70, SOT-323
Supplier Device Package SOT-323
Standard Package 3,000 pcs
REACH Status REACH Unaffected
ECCN EAR99
Win Source Part Number 642712-MMSTA42
Ultra Librarian 3D Model Ultra Librarian MMSTA42 CAD Model

Description

The 642712-MMSTA42 is a single NPN bipolar transistor designed for use in discrete semiconductor products.

  • Maximum Power Rating: 200mW
  • Voltage Breakdown (Collector-Emitter): 300V
  • Maximum Collector Current: 200mA
  • Vce Saturation: 500mV @ 2mA Base Current and 20mA Collector Current
  • DC Current Gain (hFE): 40 @ 30mA Collector Current and 10V Collector-Emitter Voltage
  • Transition Frequency: 50MHz
  • Mounting Type: Surface Mount
  • Package: SC-70, SOT-323
  • Manufacturer: Yangzhou yangjie electronic co., ltd
  • Product Status: Active
