Product Overview: MC74ACT14DR2G

The MC74ACT14DR2G is a high-performance, Hex Schmitt-Trigger Inverter integrated circuit from ON Semiconductor, designed to operate with an advanced high-speed CMOS technology. This device is particularly well-suited for wave shaping, noise filtration, and in applications requiring a high degree of precision and noise immunity in digital signal processing.

Key Features

• Logic Type: Hex Schmitt-Trigger Inverter
• Supply Voltage Range: 4.5V to 5.5V
• Operating Temperature: -55°C to +125°C
• Package / Case: SOIC-14
• Mounting Type: Surface Mount
• Output Type: Complementary
• Propagation Delay Time: 8ns at 5V
• Current - Output High, Low: 24mA, 24mA

Product Benefits

The MC74ACT14DR2G is designed for use in applications requiring a high degree of signal integrity. The Schmitt-Trigger inputs transform slowly changing input signals into sharply defined jitter-free output signals, enhancing the overall performance of digital systems. With its robust operating temperature range, this device is ideal for demanding environments.

Applications

This integrated circuit is versatile and can be used in a wide range of applications, including:

• Waveform shaping
• Noise suppression
• Signal processing
• Glitch-free clock distribution
• Communication systems
• Control systems

Quality and Reliability

ON Semiconductor is known for its commitment to quality, and the MC74ACT14DR2G is no exception. With its advanced CMOS technology, the product offers high noise immunity and low power consumption, making it a reliable choice for critical applications. The device is also RoHS compliant, ensuring adherence to environmental standards.
