SSM6J501NU,LF Toshiba Semiconductor and Storage SSM6J501NU,LF real image SSM6J501NU,LF label picture SSM6J501NU,LF label picture 2
Same model may have multiple batches, images only for reference.

SSM6J501NU,LF

Part No SSM6J501NU,LF
Manufacturer Toshiba Semiconductor and Storage
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 20V 10A UDFN6B
Datasheet
SSM6J501NU,LF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications

Categories Discrete Semiconductor Products
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 10A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 1.5V, 4.5V
Gate-Source Threshold Voltage 1V @ 1mA
Max Gate Charge 29.9nC @ 4.5V
Max Input Capacitance 2600pF @ 10V
Maximum Gate-Source Voltage ±8V
Power Dissipation (Max) 1W (Ta)
Maximum Rds On at Id,Vgs 15.3 mOhm @ 4A, 4.5V
Temperature Range - Operating 150°C (TJ)
Mounting SMD (SMT)
Case / Package 6-UDFNB (2x2)
Dimension 6-WDFN Exposed Pad
Win Source Part Number 096477-SSM6J501NU,LF
Popularity Medium
Supply and Demand Status Balance
Alternative Parts
(Cross-Reference) 		SSM6J501NU,LF(T;  SSM6J501NU;   SSM6J501NU(LF,A);

Description

The SSM6J501NU,LF is a P-channel MOSFET manufactured by Toshiba Semiconductor and Storage. This MOSFET has a maximum drain-source voltage of 20V and a maximum continuous drain current of 10A. It has a low on-resistance and a fast switching speed. The SSM6J501NU,LF is designed for various applications such as power management, load switching, and battery protection. It has a gate-source threshold voltage of 1V and a maximum gate charge of 29.9nC at 4.5V. This MOSFET is an ideal choice for those who need a reliable and efficient P-channel MOSFET for their applications.
