Same model may have multiple batches, images only for reference.

FGY75N60SMD

Part No FGY75N60SMD
Manufacturer Fairchild/ON Semiconductor
Catalog IGBTs - Single
Description Trans IGBT Chip N-CH 600V 150A 750000mW 3-Pin Power-247 Tube / IGBT 600V 150A 750W POWER-247
Datasheet
FGY75N60SMD Datasheet
Sample
ECAD Module ECAD
rohs

Shipping Information

Shipped from HK warehouse
Expected Shipping Date
Ship today if order in (HKT)
Supplier Lead-Time Call for availability
Estimate shipping fee
Enter your destination to get a shipping estimate
Estimate Shipping Fee
Pricing & Ordering $14.3766 Historical reference price : is the price that a customer announces that it is willing to pay for this component in the previous period, only for reference.
Quantity
Unit Price
Ext. Price
3+
$24.8700
$74.610
5+
$20.4060
$102.030
8+
$19.7690
$158.152
11+
$19.1310
$210.441
14+
$18.4930
$258.902
19+
$16.5800
$315.020
* The above prices does not include taxes and freight rates, which will be calculated on the order pages.
Availability: 20,643 pieces
MOQ: 3 pcs
Order Increment : 1 pcs
*Need More Quantity? *Request a Bulk Quantity Quotation?
Estimate shipping
Enter your destination to get a shipping estimate
*

Products specifications

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
IGBT Type Field Stop
VCEO Maximum Collector-Emitter Breakdown Voltage 600V
Maximum Current Collector 150A
Pulsed Collector Current 225A
Collector-emitter saturation voltage(Max) 2.5V @ 15V, 75A
Maximum Power Dissipation 750W
Total Switching Energy(Ets) 2.3mJ (on), 770μJ (off)
Input Type Standard
Gate Charge 248nC
Turn-on and Turn-off delay time 24ns/136ns
Testing Conditions 400V, 75A, 3 Ohm, 15V
Reverse Recovery Time (trr) 55ns
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package PowerTO-247-3
Win Source Part Number 204185-FGY75N60SMD
Is this a common-used part? Yes
Popularity High
Fake Threat In the Open Market 53 pct.
Supply and Demand Status Limited
Quantity per package 450
Family Name FGY75N60SMD
Introduction Date August 19, 2010
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2026
Alternative Parts
(Cross-Reference) 		IXGR120N60B; IRGP6690D-EPBF; IRGP4690DPbF; IRGP4066-EPbF;

Description

The Fairchild/ON Semiconductor 204185-FGY75N60SMD is a field stop type IGBT electronic component that comes in a through-hole mounting package. It has a maximum collector-emitter breakdown voltage of 600V and a maximum collector current of 150A. The gate charge is 248nC and the reverse recovery time is 55ns. This product is part of the Discrete Semiconductor Products category and is currently active. It comes in a PowerTO-247-3 package and has a maximum power dissipation of 750W. The total switching energy is 2.3mJ (on) and 770μJ (off) and the turn-on and turn-off delay time is 24ns/136ns. The fake threat in the open market for this product is 53% and the supply and demand status is limited. This product is packaged in a tube/rail and there are 450 pieces per package.
